The intelligent vertical rotating vehicle disc equipped with independent units is an innovative device that integrates automated parking technology and modular warehouse management concepts. It is mainly used in high-density and intelligent vehicle access scenarios. Through the vertical cyclic rotating structure and independently controlled parking units, efficient space utilization and vehicle safety management are achieved.

1、 Core structure and working principle

Vertical rotation system: driven by chains or toothed discs, it drives multiple layers of loading discs to rotate in a vertical plane. When the vehicle is parked in a fixed parking space, the system automatically rotates the target parking space to the entrance and exit position.

Independent unit design: Each parking unit has an independent support structure, independent safety locking mechanism, and independent control module, which can be started, stopped, positioned, and monitored separately, avoiding the drawbacks of "overall operation and long waiting time" in traditional three-dimensional garages.

Intelligent control system: integrated PLC+touch screen+wireless communication, supports license plate recognition, IC card, APP remote reservation access, and achieves unmanned operation.

2、 Key technological advantages

High space utilization rate

The vertical layout occupies only 1/5-1/3 of the traditional flat parking space, making it suitable for areas with scarce land resources such as urban centers, commercial complexes, and hospitals.

Operate independently to improve efficiency

Each unit can be independently called without waiting for the whole machine to cycle, and the average pick-up time is reduced to less than 60 seconds, much faster than traditional vertical loop garages.

Multiple security guarantees

Lidar ultra-high detection to prevent vehicle collisions

Chain breaking stall braking and electronic damping anti sway technology ensure stable operation

The independent unit is equipped with a safety door interlock device, which cuts off power immediately upon opening the door to ensure personnel safety

Strong adaptability to new energy

Supporting integrated parking and charging design, the vehicle automatically connects to a charging station when parked, achieving "integrated parking and charging".
